Mahsulot kodi:
1330356
Yog‘ turi:
Talablarga mos:
Alstom HTGD 90117
BS 489:1999
Siemens TLV 9013 04
Texnik spetsifikatsiyalarga mos:
DIN 51515-1 L-TD
ISO 6743-0
Mahsulot kodi:
1330356
Yog‘ turi:
Talablarga mos:
Alstom HTGD 90117
BS 489:1999
Siemens TLV 9013 04
Texnik spetsifikatsiyalarga mos:
DIN 51515-1 L-TD
ISO 6743-0
RAVENOL Turbinenöl T 68 is produced for the lubrication of gas and steam turbines as well as turbo compressors with and without transmission according to the specifications of DIN 51 515-2.
RAVENOL Turbinenöl T 68 is based on high quality mineral base oils with agents to increase the corrosion protection and aging resistance.
RAVENOL Turbinenöl T 68 is a universal mineral oil for turbines of especially chosen refined base oils with a natural high viscosity index. So-called “metal deactivators” are added to the turbine oil in addition to the normal additives in order to guarantee the excellent characteristics.
Application Note
RAVENOL Turbinenöl T 68 is used in fixed gas and steam turbines as well as electrical machines or machines driven by steam turbines like generators, compressors, pumps and transmissions.
RAVENOL Turbinenöl T 68 can also be used for the lubrication of hydraulic systems, compressors, gear transfers and bearings in case of problems of the contamination with water because a high protection against rust and oxidation is requested.
Characteristics
- an excellent thermic and oxidative stability
- an excellent viscosity temperature behaviour
- a high and stable viscosity index
- a very good oxidation stability also at very high temperatures
- a good protection against corrosion of Ferro and non Ferro metals
- an excellent water separation behaviour
- a very good air separation behaviour which excludes foam formation as far as possible
- a low pour pointa good corrosion behaviour
- an excellent water separation behaviour / demulsifying behaviour
Ko‘proq ko‘rsatish
Kamroq ko‘rsatish
Ishlab chiqaruvchining rasmiy saytida mahsulot sahifasi: ravenol.de
Kategoriyalar:
Texnik xususiyatlar
| Parametr | Qiymat | Audit |
|---|---|---|
| Kenglik, mm | 580 | |
| Uzunlik, mm | 580 | |
| Balandlik, mm | 885 | |
| Og‘irlik, kg | 198.171 | |
| Viskozite | 68 | |
| Brand | RAVENOL | |
| Zichlik 20°С da, g/cm³ | 868 | EN ISO 12185 |
| Viskozite 100°С da, mm²/s | 9 | DIN 51562-1 |
| Viskozite 40°С da, mm²/s | 69 | DIN 51562-1 |
| Viskozite indeksi VI | 104 | DIN ISO 2909 |
| Qotish harorati, °C | -30 | DIN ISO 3016 |
| Yong‘in chiqish harorati, °C | 262 | DIN EN ISO 2592 |
0 ta mahsulotga sharhlarRAVENOL Turbinenöl T 68
